| Battery Type |
LiFePO₄ (Lithium Iron Phosphate) |
| Nominal Voltage |
51.2V (commonly referred to as “48V”) |
| Nominal Capacity |
100Ah |
| Energy Capacity |
5120Wh (5.12 kWh) |
| Cell Configuration |
16 cells in series (16S) |
| Chemistry |
LiFePO₄ |
| Cycle Life |
≥ 4000–8000 cycles @ 80% DOD |
| Recommended Charge Voltage |
56.8V – 57.6V |
| Float Charge Voltage |
54.0V – 54.5V |
| Max Continuous Charge Current |
100A |
| Max Continuous Discharge Current |
100A |
| Peak Discharge Current |
200A (≤ 5 sec) |
| Discharge Cut-off Voltage |
40.0V – 42.0V |
| Depth of Discharge (DOD) |
Up to 100% |
| Built-in BMS Protection |
Overcharge, Over-discharge, Over-current, Short-circuit, Over-temp |
| Communications |
Optional CANbus / RS485 |
| Operating Temp (Charge) |
0 °C to 55 °C |
| Operating Temp (Discharge) |
–20 °C to 60 °C |
| Storage Temperature |
–10 °C to 45 °C |
| Self-Discharge |
<2% per month |
| Terminal Type |
M8 / M10 bolt or telecom-grade studs |
| Case Material |
Steel or ABS (model dependent) |
| Mounting |
Rack / Floor mount |
| Weight |
Approx. 50–60 kg (model dependent) |
| Dimensions (L×W×H) |
Approx. 550 × 500 × 220 mm (typical) |
| Scalability |
Can be connected in series/parallel for higher voltage/capacity |
| Typical Telecom Applications |
BTS sites, Remote OSP power, UPS backup, DC power systems |
| Certifications |
CE / UL / IEC (model dependent) |
| Warranty |
3–5 years (manufacturer dependent) |
