| Specification | Details |
|---|---|
| Model | DJDC 51.2V300Ah |
| Usable Energy | 15.36 kWh |
| Cell Type | LiFePO₄ (LFP) |
| Nominal Voltage | 51.2 V |
| Operating Voltage Range | 40 – 58.4 V |
| Nominal Charge Current | 150 A |
| Nominal Discharge Current | 150 A |
| Max. Charge Current | 200 A |
| Max. Discharge Current | 300 A |
| Communication | CAN, RS485, Bluetooth, WiFi |
| Dimensions (mm) | 805 × 440 × 265 (with casters) |
| Weight | 135 kg |
| Operating Temperature | Charge: 0 – 45℃ / Discharge: -10 – 60℃ |
| Relative Humidity | 0 – 85% |
| Max. Operating Altitude | 2000 m |
| Mounting Method | Wall-mounted / Grounded |
| Certifications | MSDS, IEC, RoHS, CE, UN38.3 |
Solar Energy Storage System Lithium Battery 51.2V300Ah
Key Features
DJDC 51.2V300Ah LiFePO₄ battery offers 15.36kWh usable energy with a 51.2V nominal voltage.
It supports up to 200A charge and 300A discharge current.
Built-in communication: CAN, RS485, Bluetooth, WiFi.
Compact size 805×440×265 mm, weight 135kg.
Certified with MSDS, IEC, RoHS, CE, UN38.3 for safety and reliability.
