| Model |
DJ 6-4.5 |
| Battery Type |
Sealed Lead Acid (VRLA / AGM) |
| Nominal Voltage |
6 V |
| Nominal Capacity |
4.5 Ah (20 hr Rate) |
| Number of Cells |
3 |
| Energy |
27 Wh |
| Design Life |
3–5 years (float use) |
| Cycle Life |
~300–500 cycles @ 50 % DOD |
| Recommended Charge Mode |
Constant Voltage Charge |
| Standby (Float) Voltage |
6.75 – 6.90 V @ 25 °C |
| Cycle Charge Voltage |
7.20 – 7.50 V @ 25 °C |
| Max Initial Charge Current |
1.35 A |
| Self-Discharge |
≤ 3 % per month |
| Operating Temp (Charge) |
0 °C to 40 °C |
| Operating Temp (Discharge) |
–15 °C to 50 °C |
| Storage Temperature |
–15 °C to 40 °C |
| Terminal Type |
Faston Tabs (F1 / F2) |
| Container Material |
ABS (Flame Retardant Optional) |
| Installation Position |
Sealed, any orientation |
| Maintenance |
Maintenance-Free |
| Weight |
Approx. 0.9–1.1 kg |
| Dimensions (L×W×H) |
Approx. 90 × 70 × 101 mm |
| Typical Applications |
Emergency Lights, UPS, Security Systems, Toys, Small Electronics |
