Specifications Constant Voltage
| Parameter | Specification |
|---|---|
| Charging Method | Constant Voltage (CV) Charging |
| Standby / Float Voltage | 13.6 – 13.8 V @ 25 °C |
| Cycle Charge Voltage | 14.5 – 14.9 V @ 25 °C |
| Maximum Initial Charge Current | 1.5 A (current limited) |
| Recommended Charge Current | 0.1C – 0.3C |
| Discharge Cut-off Voltage | 10.5 V |
| Temperature Compensation | −3 mV / cell / °C |
| Typical Recharge Time | 8 – 12 hours |
Charging Guidelines
Use a constant voltage charger specifically designed for VRLA/AGM/Gel batteries.
For standby or float operation, maintain 13.6–13.8 V to keep the battery fully charged without overcharging.
For cycle or deep-discharge applications, use 14.5–14.9 V to restore full capacity quickly and efficiently.
Limit the initial charging current to 1.5 A to prevent overheating and extend battery life.
Proper charging improves performance, safety, and overall service life of the battery.
