| Model |
DJ 6–7 |
| Battery Type |
Sealed Lead Acid (VRLA / AGM) |
| Nominal Voltage |
6V |
| Nominal Capacity |
7Ah (20Hr Rate) |
| Number of Cells |
3 |
| Design Life |
3–5 years (standby use) |
| Cycle Life |
300–500 cycles @ 50% DOD |
| Energy Capacity |
42Wh |
| Constant Voltage Charge |
Yes |
| Standby (Float) Voltage |
6.80 – 6.90V @ 25°C |
| Cycle Charge Voltage |
7.25 – 7.45V @ 25°C |
| Max Initial Charge Current |
2.1A |
| Internal Resistance |
≤ 20 mΩ (approx.) |
| Self-Discharge |
≤ 3% per month |
| Operating Temp (Charge) |
0°C to 40°C |
| Operating Temp (Discharge) |
–15°C to 50°C |
| Storage Temperature |
–15°C to 40°C |
| Terminal Type |
F1 / F2 Faston Tab |
| Container Material |
ABS (Flame Retardant Optional) |
| Installation Position |
Any position (sealed design) |
| Maintenance |
Maintenance-Free |
| Weight |
Approx. 1.0 – 1.2 kg |
| Dimensions (L×W×H) |
Approx. 151 × 34 × 94 mm |
| Typical Applications |
Emergency Lights, UPS, Security Systems, Toys, Medical Devices, Backup Power |
