DJDC VRLA AGM based 12V 200Ah Dry Battery

Battery Type: Valve Regulated Lead Acid (VRLA) — AGM (Absorbent Glass Mat), sealed maintenance-free
Nominal Voltage: 12 V
Rated Capacity: 200 Ah (10-hour rate @ 10.8 V)
Float Charge Voltage: 13.5 – 13.8 V @ 25 °C
Cyclic Charge Voltage: 14.4 – 14.7 V @ 25 °C
Maximum Charge Current: 60 A
Maximum Continuous Discharge Current: ~500 – 800 A (varies by manufacturer)
Peak Discharge Current: ~1000 – 2000 A (short bursts)
Internal Resistance: ~2.5 – 4.0 mΩ (fully charged)

Categories: Uncategorized

Typical 12V 200Ah VRLA AGM Battery Specification

Parameter	Typical Value
Battery Type	Valve Regulated Lead Acid (VRLA) — AGM (dry, maintenance-free)
Nominal Voltage	12 V
Nominal Capacity	200 Ah @ 10 hr rate (10.8 V)
Float Charging Voltage	13.5 – 13.8 V @ 25 °C
Cyclic Use Voltage	14.4 – 14.7 V @ 25 °C
Maximum Charge Current	~60 A
Maximum Discharge Current	~1000 – 2000 A (5 s surge)
Internal Resistance	~2.5 – 4.0 mΩ (fully charged)
Design Life	8 – 12 + years (float service)
Weight	~55 – 65 kg
Dimensions (L×W×H)	~520 × 238 × 218 mm (total ~220 mm)
Container Material	Flame-retardant ABS
Operating Temp – Charge	0 °C to ~50 °C
Operating Temp – Discharge	~-15 °C to ~50 °C
Self-Discharge	~<3 % per month @25 °C
Terminal Type	M8/F10/F16 or T-term equivalents
